i5 Series
i5 M4
Model
i5 M4.5
i5 M4.8
Controller
i5
i5
X/Y/Z Axis Travel
1000/610/650 mm
1300/700/700 mm
Table Size
1200x500 mm
1400x700 mm
Max.Load
600 kg
1000 kg
Spindle Speed
8000/10000 (opt) Rpm
8000/10000 (opt) Rpm
Spindle Taper
BT40/BT50 (opt)
BT40/BT50 (opt)
X/Y/Z Rapid Feed
32/32/30 m/min
24/24/20 m/min
Auto Tool Change
Arm 24 T
Arm 24 T
Tool Change Time
2.5 s
3.5 s
X/Y/Z Positioning Accuracy
0.016/0.012/0.012 mm
0.020/0.012/0.012 mm
X/Y/Z Axis Repeatability
0.010/0.008/0.008 mm
0.012/0.010/0.008 mm
General Power Capacity
25 kVa
37 kVa
Spindle Motor
11/15 kW
15/18.5
Floor Space
4400 x 2565 mm
4800 x 3000 mm
Machine Weight
7000 kg
11000 kg
