SMTCL Series
HTC
Model
HTC3630
HTC3650
Max. Turning leght
300 mm
500 mm
Max. Swing diameter over bed
ø550 mm
ø550 mm
Max. Swing diameter over slide
ø320 mm
ø320 mm
Max. Cutting diameter over slide
ø360 mm
ø360 mm
Spindle nose
A2-6
A2-6
Chuck diameter
8"
8"
Diameter of spindle bore
ø65 mm
ø65 mm
Spindle speed
50-4500 r/min
50/4500 r/min
Main motor power
15/11 kW
15/11 kW
X axis stroke
200 mm
200 mm
Z axis stroke
350 mm
550 mm
Tail stock stroke
-
350mm
Size of tool shank
25x25 mm
25x25 mm
Rapid feed (X/Z axis)
30/30 m/min
30/30 m/min
Net weight
4000 kg
4300 kg
Machine dimensions (LxWxH)
2200x1890x1945 mm
2700x1890x1945 mm
