SMTCL Series

VMC1000B

Model VMC1000B
Controller Fanuc
X/Y/Z Axis Travel 1000/610/650 mm
Table Size 1200x500 mm
Max.Load 600 kg
Spindle Speed 8000/10000 (opt) Rpm
Spindle Taper BT40/BT50 (opt)
X/Y/Z Rapid Feed 32/32/30 m/min
Auto Tool Change Arm 24 T
Tool Change Time 2.5 s
X/Y/Z Positioning Accuracy 0.016/0.012/0.012 mm
X/Y/Z Axis Repeatability 0.010/0.008/0.008 mm
General Power Capacity 25 kVa
Spindle Motor 11/15 kW
Floor Space 4400 x 2565
Machine Weight 7000 kg
