Conventional Machine

CW 6280B/3000

Technical Specification

Specification CW 6280B/3000
Distance Between Center 3000 mm
Swing over Carriage 480 mm
Swing over Bed 800 mm
Max. cross travel of lower slide 500 mm
Max. travel of top slide 200 mm
Max. travel of tailstock quill 250 mm
Swing over Gap 1000/310mm
Spindle Bore 104 mm
Spindle Speeds  18 speeds 5.4-720 r/min
Width of Bed 600/RC52
Main motor power 11 or 15 kW
Net Weight 5500 kg

Standard Accessories

  • 3 – jaw chuck Ø 315
  • 4 – jaw chuck Ø 500
  • Face plate Ø 800
  • Steady rest Ø 40 – Ø 320
  • Follow rest Ø 30 -  Ø 130
  • Center and sleeve metric
  • Lillumination, cooling
  • Tools
